Amphenol Fiber Systems International (FSI) ARINC 801 Cylindrical Fiber Optic Connectors are based on the commercial ARINC 801 specification and feature a removable alignment sleeve retainer (ASR). The ASR provides ease of termini end-face cleaning, guide pins for precision alignment, and a scoop-proof shell design. These connectors are designed for aerospace and military applications and are offered in standard D38999 plug and receptacle shells. The companion ARINC 801 terminus uses a standard 1.25mm ferrule and sleeve that can be terminated with standard LC termination procedures. Amphenol FSI ARINC 801 Cylindrical Fiber Optic Connectors are ideal for commercial airframe, avionics, military radar, SATCOM systems, and RF-over-fiber applications.
Features
Qualified to the ARINC 801 specification
Precision alignment and components provide excellent optical performances
Supports standard suite of 38999 backshells and accessories
Supports APC termini for RF-over-fiber and other applications requiring low back reflection
Removable ASR facilitates termini cleaning and maintenance
High-density arrangements with up to 32 channels
Applications
Commercial airframe
Avionics
Military radar
SATCOM systems
RF over fiber
Specifications
11 to 25 shell size range
2- to 32-hole layouts
-55°C to +125°C temperature range
1000hrs at +100°C
Up to 300Grms vibration levels
500 mating cycles
100hrs humidity exposure
Single-mode or multimode options
Loose (pull-proof) or tight (non-pull-proof) cable structure options
